INDUSTRY ORGANIZATIONS PNO, ETG, AND CIA
OUR MEMBERSHIPS AS AN EXPRESSION OF OUR RESPONSIBILITY
We have been involved in leading industry organisations such as the Profibus User Organisation (PNO), the EtherCAT Technology Group (ETG) and the CAN in Automation (CiA) group for many years, actively shaping the standardisation and further development of innovative technologies.
Technical collaboration brings valuable input directly into our product development process. This allows us to provide practical, future-proof, standards-compliant solutions, giving us a clear advantage over the competition.
The PROFIBUS User Organisation is the driving force behind the worldwide PROFIsafe, PROFINET and PROFIBUS automation standards. As members, we contribute our expertise to technical working groups to ensure that our sensor solutions can be seamlessly integrated into modern automation environments.
Your PROFIsafe contact is Andreas Meyer. With his many years of experience and expertise, he is a leading PROFIsafe specialist.
TRT42/S3 SIL2/PLd
Absolute multiturn encoder
• Magnetic sensor technology with absolute multiturn gearbox for 4096 revolutions
• Optional slewing ring software for unrestricted operation with gear ratios
• SIL2/PLd certification in accordance with IEC 61508 and ISO 13849-1
• Housing made of seawater-resistant aluminum or selectable stainless steels
NBT-D SIL2/PLd
Rotor hub sensor
• Combination of inclination and rotation rate sensor in MEMS design
• Measurement of rotational speed without direct connection to the axis of rotation
• SIL2/PLd certification for safety-critical applications
LBBT SIL2/PLd
Safety Ring Encoder
• Inductive, wear-free measuring principle ensures durability and maintenance-free operation
• High resolution (up to 22 bits) for precise position and speed detection
• 2-in-1 sensor solution for functionally safe and additionally fast data transmission
• Compact design with large hollow shaft (50–150 mm)
NVT/S3 PLd
Vibration sensor
• Acceleration detection using MEMS sensors
• Choice of different frequency bands and filter types
• Sturdy aluminum housing, suitable for harsh environmental conditions
• PLd certification for safety-critical applications
As a member of the EtherCAT Technology Group, we rely on EtherCAT for real-time, deterministic communication. Our sensors and encoders with EtherCAT and Safety over EtherCAT (FSoE) offer precise synchronization for demanding automation tasks.
Your FSoE contact is Dr. Jan Kühn. With his expertise and specialization, he is your expert in the field of EtherCAT and Safety over EtherCAT.
TRK38/S3 SIL2/PLd
Compact single-turn encoder
• Ultra-compact design with a diameter of 38 mm
• High resolution of 16 bits (65,536 steps/360°)
• SIL2/PLd certification according to IEC 61508 and ISO 13849-1
• Housing designs in aluminum or stainless steel – also magnetically shielded
LBEK SIL2/PLd
Safety Ring Encoder
• Inductive, wear-free measuring method for high durability.
• High resolution (up to 22 bits) for precise position and speed detection.
• 2-in-1 sensor solution for functionally safe and additionally fast data transmission.
• SIL2/PLd certification for safety-critical applications.
TRK78/S3 SIL2/PLd
Absolute multiturn encoder
• Magnetic sensor technology with absolute multiturn gearbox for 4096 revolutions
• ATEX & IECEx certification for potentially explosive areas Zone 1/21
• SIL2/PLd certification for functional safety
• Safe position and speed based on 16-bit resolution
• Aluminum or stainless steel housing
CAN in Automation e.V. is the international user and manufacturer association for CAN-based communication. With our CANopen-compatible products, we particularly support applications in mechanical engineering and safety-critical areas.
As Chairman of Functional Safety at CAN in Automation, Robert Steinebach brings with him in-depth technical expertise, particularly in the field of CANopen Safety.
LBBN SIL2/PLd
Safety Ring Encoder
• Space-saving inductive design for compact machines and robot controllers
• Hollow shaft design with inner diameters from 50 to 150 mm
• 2-in-1 sensor solution for functionally safe and additionally fast data transmission
• SIL2/PLd certification for safety-critical applications
TBN/S4 SIL2/PLd
Bearingless safety encoder
• Bearingless design with external magnet for high installation flexibility
• Flat housing with plug or cable outlet, optionally available as a circuit board
• Up to 16-bit resolution for high precision in position and speed detection
• SIL2/PLd certification according to IEC 61508 and ISO 13849-1
ARN SIL2
Absolute Multiturn Encoder
• High-resolution encoder with 20 bits/360° (22 bits for the ABN single-turn encoder)
• Absolute multiturn gear with a measuring range of 4096 revolutions
• CANopen Safety interface for safe position and speed values
• SIL2 certification for safety-critical applications
NVA/S3 PLd
Capteurs de vibrations
• Détection des accélérations à l'aide de capteurs MEMS
• Différentes bandes de fréquences et types de filtres réglables
• Deux sorties de commutation de sécurité supplémentaires (surveillées en interne) et deux sorties analogiques
• Certification PLd pour les applications critiques en matière de sécurité
